| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 32-12SF Pro | 32 | 6 | 8 | 12 | 230 | 50 | 500 | 220 | DN32 – G2 |
 |
Basic 25-5SB | 25 | 1.8 | 3.2 | 5 | 115/230 | 50/60 | 85/60/40 | 130 | G1 1/2 |
 |
Basic 25-6S | 25 | 2 | 3.5 | 6 | 115/230 | 50/60 | 100/70/55 | 130/180 | G1 1/2 |
 |
Basic 25-8SB | 25 | 3.2 | 6 | 8 | 115/230 | 50/60 | 245/190/135 | 180 | G1 1/2 |
 |
Basic 25-8S | 25 | 3.2 | 6 | 8 | 115/230 | 50/60 | 245/190/135 | 180 | G1 1/2 |
 |
Basic 25-20 | 25 | 9 | 14 | 20 | 230 | 50/60 | 1000 | 230 | G1 1/2 |
 |
Basic S 32-4S | 32 | / | / | 4 | 230 | 50 | 50/40/30 | 180 | G2 |
 |
Basic S 25-5S | 25 | / | / | 5 | 230 | 50 | 65/50/40 | 130/180 | G1 1/2 |
