| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
EPA 25-20ZA | 25 | 3 | 17 | 20 | 250 | 50/60 | 350 | 208 | Chuck |
|
EPA 25-20ZAX | 25 | 3 | 16 | 20 | 270 | 50 | 350 | 168 | Chuck |
 |
LPA 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/150/180 | G1 1/2 |
 |
Mega S 50-10F | 50 | 16.5 | 5.5 | 10 | 220~240 | 50/60 | 480 | 280 | /Flange |
 |
Master SD 25-6 | 25 | 2 | 3.5 | 6 | 220~240 | 50/60 | 39 | 130/180 | G1 1/2 |
 |
Classic 20-4 | 20 | 1.5 | 2 | 4 | 230 | 50/60 | 22 | 130 | G1 |
 |
Mega S 80-8F | 80 | 37 | 5 | 8 | 230 | 50/60 | 750 | 360 | DN80/Flange |
 |
Basic 50-12SF Pro | 50 | 15 | 9 | 12 | 230/380 | 50 | 1000 | 280 | DN50 |
