| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Classic 32-4 | 32 | 1.7 | 2 | 4 | 230 | 50/60 | 22 | 180 | G2 |
 |
Master 20-6 | 20 | 2 | 3.2 | 6 | 220~240 | 50/60 | 39 | 130 | G1 |
 |
Basic 25-7S Pro | 25 | 3.5 | 4.4 | 7 | 220~240 | 50 | 140/115/70 | 130/180 | G1 1/2 |
 |
Basic 25-7S | 25 | 2.5 | 3.8 | 6.5 | 115/230 | 50/60 | 130/110/90 | 130/180 | G1 1/2 |
 |
Basic 25-7SB | 25 | 2.5 | 3.8 | 6.5 | 115/230 | 50/60 | 130/110/90 | 130 | G1 1/2 |
 |
Basic 15-9S | 15 | 1 | 5.5 | 9 | 115/230 | 50/60 | 120/80/65 | 160 | G3/4 |
 |
Basic 50-12SF | 50 | 15 | 9 | 12 | 380 | 50 | 1000 | 280 | DN50 |
 |
Basic S 25-6S | 25 | / | / | 6 | 230 | 50 | 70/60/50 | 130/180 | G1 1/2 |
